技术参数Technical Parameter

锭数
Number of Spindle

锭

50-100锭
50-100spindles

线速度
Linear Velocity

m/min

Max.700

筒管规格
Bobbin Size

m

Φ42×240-320

卷绕容量
Winding Capacity

kg

1.5

驱动装置
Drive Device

环形龙带
Circular Apron Belt

往复装置
Traverse Device

滚珠丝杆 Ball Screw

往复卷取电机功率
Power of Traverse Winding Motor

KW

0.55

驱动电机
Power of Driving Motor

50锭3KW, 80锭4KW, 100锭5.5KW
3KW for 50spindles, 4KW for 80 spindles, 5.5KW for 100 spindles

供丝
Suitable Yarn

各种化纤, 长丝, 人造丝等
Chemical Fiber, filament, rayon silk

卷取形式
Winding Type

经纱工卷取,纬纱式卷取,复合式卷取,组合式卷取
Warp wind, weft wind, compound wind, combined wind

整机尺寸
Overall Size

mm

1500+1300×N(节数)×1250×1850
1500+1300×N(sections)×1250×1850
