电脑多头绗绣机

1. 集电脑绗缝、绣花于一体
2. 自动换色，任意选择机头绗缝、绣花
3. Y向无限连续绗绣，前后置有自动张紧系统
4. 使用3.5英寸软盘与普通绣花机通用
5. 采用独立压脚式操作，使所生产的产品有立体美感
6. Y向滚轴式设计，布匹可连续绣作或绗缝
7. 操作简单、便捷、易学等优点。
8. 转速控制、断电保护、断电记忆功能
9. 花样缩放大小、旋转方向绣作功能
10. 断线检测、回退绗绣
11. 高低速进、退功能
12. 剪线系统，剪线长度可控制。勾线集中系统，平稳可靠（选装）
13. Y方向采用先进的独特的传动机构，该机构已获国家专利

1. Computerized quilting & embroidery .
2. Automatic color-choosing and selecting any head you like to quilt and embroider.
3. Continuous quilting & embroidery in Y direction, and automatic back & forward tightening and loosening system are available.
4. Adopt 3.5 floppy disk and it can be used with common embroidery machine.
5. Adopt independent foot-pressing system to obtain stereoscopic aesthetic effect of each finished product.
6. Features of rolling design in Y direction,continuous embroidery &quilting on the cloth .
7. Features such as easy and convenient operation.
8. Functions of speed-control. Protection and memorizing in case of electricity shortage.
9. Free choice to size of each pattern and embroidering while gyrating directions.
10. Thread-breakage detection system and embroidering in case of failure to embroider.
11. Speed-changing in moving material forward and backward.
12. Thread-cutting system: control the length of thread that needs cutting. Integrated thread crossing system: stable and reliable.(selected design)
13. Adopt advanced & unique transmission structure in Y direction. It is national Patent.

机型 Model HY3-22-6” HY3-26-5” HY3-33-4”
头数 Number of head 22 26 33
针间距 Space of needle 152.4 127 101.6
针数 Needles 1 √ √ √
3 √ √ √
绗绣尺寸（横）mm
embroidery size
(horizontal) X向（单个花型）
X（single pattern） 152.4/304.8 127/254 101.6/304.8
绗绣总宽度
width of embroidery 3352.8 3302 3352.8
外型尺寸
Dimension 长 Length 5340 5340 5340
宽 Width 980
高 Height 1847
绗缝速度 speed 250-880/RPM
机头线色 thread color per head 1-3
针迹长度 length of stitch 二进法（binary system） 0.15-12.7mm
储存针数 saving stitch number 120万针 （120,000,000stitches）
花样储存容量 capacity for storing patterns 100个花样 100patterns
额定功率 Power 4.5-5千瓦 （4.5-5KW）
电压 Voltage 三相Three-phase 220V/380V (50HZ/60HZ)
机重量 Weight 2.1T 2.37T 2.6T
本系列可接受非标头数针间距生产
These serials can be produced at customer’s requirements for different heads.
