ESA推出XS712 ATOM高性能一体机
意萨电子科技（上海）有限公司
2012年01月05日 来源：中国纺机网
产品信息
ESA IPC系列产品包括工业电脑、工业面板一体机、嵌入式平板电脑、Box PC、VESA及工业显示器产品，适用于各种工业环境要求
XS7系列产品采用精准的工业设计及高质量的元件，使XS7系列产品具有更好的机械工业特性，可以在高粉尘、高振动、宽温等各种复杂环境中使用，并保证其性能的稳定。
无风扇型工业电脑一体机采用触摸屏操作模式，支持从7寸宽屏到19寸等多型号产品，内置Intel ATOM无风扇型CPU处理器，可提高性能降低能耗。
此外，ESA针对某些特殊行业应用，提供适合复杂环境的产品选项（如制药及化工行业）。
ESA的XS7工业电脑一体机产品符合EC标准，支持c-UL及UL-us(UL508 CSA C22.2 No. 14-M95 – 认证中)，ATEX (Zone 2/22, category 3 G/D)认证，保证产品使用的稳定，并保证您系统的安全。
| Display | |
| Size | 12" |
| Technology | TFT |
| Colors | 262 K |
| Backlight | CCFL (2 lamps) |
| Lamp life (min. at 25 °C) | 50.000 h |
| Resolution pixel h-v (inches) | 800 x 600 pixels |
| Touch screen | |
| Type | Analog resistive (4 wires) |
| Motherboard / CPU | |
| CPU Fan | Intel® ATOM Dual core 1,66GHz D510 |
| Chipset | ICH8M |
| FSB | 667 MHz |
| System memory | |
| RAM | up to 2GB DDR2 SODIMM 200pin |
| Disk Drives | |
| Hard disk / SSD (optional) | min. 160 GB SATA 2,5" / SSD 8GB |
| Compact Flash Slots | |
| Internal (optional) | 1 x |
| External (optional) | 1 x |
| Interfaces | |
| RS232 serial port | 3 x |
| RS485 serial port | 1 x |
| USB on front (2.0) IP65 | 1 x |
| USB on rear (2.0) | 4 x |
| Green led on front | 1 x |
| PS/2 keyboard / mouse port | 1 x |
| PCI slots | |
| PCI Slot 1 (optional) | 1 x |
| PCI Slot 2 (optional) | 1 x |
| Mini PCIe (optional) | - |
| PCIe slot 1x (optional) | 1 x |
| Wi-Fi | |
| Wi-Fi card (optional) | PCI / USB / PCIe 1x |
| Video / Audio | |
| Video port | 1xVGA |
| Audio port | MIC IN + Line IN + Line OUT |
| Networks | |
| Ethernet ports RJ45 | 2 x Ethernet 10/100/1000 Mbit |
| Size | |
| External (W x H x D) (mm) | 336 x 256 x 81 (mm) |
| Cut-out (W x H) (mm) | 321 x 240 (mm) |
| Clock | |
| Back-up with battery | 1 x |
| Technical specifications | |
| Power supply | 18...30 Vcc max 75 W |
| Power consumption (24 Vcc - basic config - NO PCI CARDS) | 43 W |
| Protection level | IP 66 frontal |
| Operating temperature (°C) | 0...+50 |
| Storage temperature (°C) | -20...+65 |
| Humidity | 90% |
| Weight (kg) | ~ 5 |
| Certifications | CE, cULus (in progress), Atex (Group II – cat.3 G D) / Environment EN 60068-2-6/27/30 / Immunity EN 61000-6-2 / Emissions 61000-6-4 |
| Optional kits | |
| Frontal INOX with True-flat Touch screen | Yes - No LED/USB frontal |
| RAID 2xHDD function | Yes |
| Removable HDD/SSD | Yes |
| DVD-RW Sata | External (optional) |
| Hook mounting | Yes |
| Operating system | |
| Operating system | Win7 - Win® XP Pro SP3 MUI - Xpe |
