JM-810 单针高头车 jM-810 SINGLE NEEDLE POSTBEED SEWING MACHING

适用与运动鞋、女鞋、马靴、袋子等的车缝及饰缝。
■ 采用全回转垂直梭头、连接杆式的天平。车缝效果良好。
■ 本缝下送，车厚薄物均匀顺畅自如，尤其车缝多层厚皮料，效果奇佳。
■ 缝目大小调节容易。
■ 轻压倒缝杆便可轻松倒缝，操作简便。
■ 釜座位于针的右方 ，方便于童鞋及各式鞋类的车缝。
规格
■ 最高缝速：2500针/分钟
■ 最大缝目：5.0mm
■ 使用针：DP×5
■ 针棒行程：33.5mm
■ 押脚提针：12mm

Suitable for sports shoes, lady shoes, jackboots, bags &hats etc.
■ Excellent sewing effects and first class quality thank to vertiarotating hook and link take-up lever.
■ Loc stitch with drop feed can promise a smooth sewing guilty on either thin or thick materials, especially on the multi-layered leather.
■ Easily adjustable stitch length variation.
■ Back tacking only with gentle pres on the backing bar, convenient operation.
■ Easy guiding of work when sewing on close shoe uppers e g. children's because the post is arranged to the right of the needle.
SPECISICATION
■ MA×SEWING SPEED:2500.S.P.M
■ MA×STITCHLENGTH:5.0mm
■ NEEDLE SYSTEM:DP×5
