转向阀
发布时间:2011-03-10
|
|
详细部件分解示意图: |
|
(1)阀基座(2)阀体(3)铜管(4)阀帽 (5)O型圈(6)选择转子 (7)阀SI (8)轴承座 (9)滚珠轴承 (10)V-型圈(11)转矩臂(12)十字联轴节(13)螺线管固定片 (14)螺线管支架 (15)连接器(16)交叉旋转螺线管 (17)O型圈(18)乙烯基管(19)管子连接器 (20)O型圈 (21)管子连接器(M)(22)管子连接器(H) (23)输出管 (24)管子固定器 (25)垫圈 |
1.Valve seat 2.Valve body 3.Copper tube 4.Valve cape 5.O-ring 6.Selection rotatar 7.Valve cylinder 8.Gear seat 9.Ball gear 10.V-ring 11.Rotary torque arm 12.Cross coupting 13.Thread pipe fastener 14.Thread pipe frame 15.Connector 16.Cross ratary thread pipe 17.O-ring 18.Vingl pipe 19.Pipe connector 20.O-ring 21.Pipe connector(M) 22.Pipe connector(H) 23.Ourput tube 24.Tube fastener 25.Washer |
