MB541型自动宽幅对折卷筒机(MB541 Automatic Broad-width Doubling and Rolling Machine)
发布时间:2014-07-04
用途 Purpose
本机适用于棉纺织厂、印染厂的整理车间,对各类阔幅、特阔幅织物对折后卷取成圆卷,便于包装和运输。有200到360各种规格供选用。
It applies to printing and dyeing, weaving factory, silk factory finsihing factory finsihed or semi-finished cloth by rolling into scroll, easy to package and transport. There are all types from 200 to 360.
主要特点 Characteristics
1. 采用红外光电对中装置,达到全自动齐边的目的。
2. 变频调速:5-60m/min(无级)。
3. 进布部分采用电动吸边器,使进布时布料基本处于对中装置,有利于对折效果。
4. 运用数字计长仪进行布匹测长,米、码可以换算,计长准确。
1. The use of photovoltaic in the infrared device, so that the fabric edges neatly.
2. Conversion controlling: 5-60m/min(step-less)
3. Use of electric inhale machine to make the cloth in the middle place.
4. High-precision electrically countless machine, it can cut meter and yard, precise and reliable in calculation.
技术参数 Technical parameter
型式 (Type) |
平面卷取式 Plane rolling |
工作幅度(mm) Working range(mm) |
2000-3600 |
卷取速度(m/min) Rolling speed(m/min) |
5-60m/min(无级) Step-less |
卷取齐边误差(mm) Range of error(mm) |
≤6 |
机械尺寸:长*宽*高(mm) Size: length*width*height(mm) |
3500*3500*3000 |
整机重量(kg) Weight(kg) |
1650 |
